There are two CNIs that are avaiable for container networking in Tanzu kubernetes guest clusters: Antrea and Calico
In this post, lets take a closer look at Calico and how to deploy and use Calicoctl
Pods can fail if they do not get an ip address from the CNI. A common error is:
k get events
4m31s Warning FailedCreatePodSandBox pod/validationservice-59cbc867c-pt7k5 (combined from similar events): Failed to create pod sandbox: rpc error: code = Unknown desc = failed to setup network for sandbox "2c0a340dfe947ad27564e0b73d5efac7f13951a77aa9c0a6e5e5d90b7d299e4c": rate: Wait(n=1) would exceed context deadline
4m31s Warning FailedCreatePodSandBox pod/validationservice-59cbc867c-qhdjr (combined from similar events): Failed to create pod sandbox: rpc error: code = Unknown desc = failed to setup network for sandbox "c0f9ecf1f5a73954bbc3733ff1342fec6896d339bc6039473765e5f143b7850d": rate: Wait(n=1) would exceed context deadline
To view the ip blocks provided by IPAM(Calico) in the Tanzu Kubernetes cluster
Login to the tkc cluster
k vsphere login -u administrator@vsphere.local --server=kube.gs.labs --insecure-skip-tls-verify --tanzu-kubernetes-cluster-name demo-tkc --tanzu-kubernetes-cluster-namespace gs-dev
View the IPAM blocks
root@debian:~# k get ipamblocks
NAME AGE
192-168-200-0-26 22d
192-168-200-192-26 22d
192-168-200-64-26 24d
In order to find out how many IPs are used and to get more details from the Calico CNI, we will need to use Calicoctl
To install the calicoctl, the easiest way to do this is to download the binary - more info here: https://docs.projectcalico.org/getting-started/clis/calicoctl/install
root@debian:~# curl -o calicoctl -O -L "https://github.com/projectcalico/calicoctl/releases/download/v3.20.0/calicoctl"
% Total % Received % Xferd Average Speed Time Time Time Current
Dload Upload Total Spent Left Speed
100 615 100 615 0 0 1762 0 --:--:-- --:--:-- --:--:-- 1757
100 43.2M 100 43.2M 0 0 17.1M 0 0:00:02 0:00:02 --:--:-- 38.4M
root@debian:~# chmod +x calicoctl
root@debian:~# ./calicoctl --allow-version-mismatch ipam show --show-blocks
+----------+--------------------+-----------+------------+-----------+
| GROUPING | CIDR | IPS TOTAL | IPS IN USE | IPS FREE |
+----------+--------------------+-----------+------------+-----------+
| IP Pool | 192.168.200.0/24 | 256 | 11 (4%) | 245 (96%) |
| Block | 192.168.200.0/26 | 64 | 3 (5%) | 61 (95%) |
| Block | 192.168.200.192/26 | 64 | 4 (6%) | 60 (94%) |
| Block | 192.168.200.64/26 | 64 | 4 (6%) | 60 (94%) |
+----------+--------------------+-----------+------------+-----------+
You need to use --allow-version-mismatchas the latest version of calicoctl wont run with older versions of Calico by default.
root@debian:~# ./calicoctl version
Version mismatch.
Client Version: v3.20.0
Cluster Version: 3.11.2
Use --allow-version-mismatch to override
For additional command line parameters, refer https://docs.projectcalico.org/reference/calicoctl/overview
